Preparation For Downloading
33
Copying Function Code To Your Computer
In order to download function code to a printer if using a serial or parallel port,
the function code file must reside in a PC or laptop computer running any of
the following operating systems: MS-DOS
®
, PC-DOS™, or DOS session on
Windows 95/98, Windows NT or Windows 2000.
Note that the downloaded file,
xxxxxx
.exe, is a compressed executable file.
Leave the file as it is. Do not try to execute the file.
C320xD
C5640D
(Note 1)
D printers using
PCL-II emulation
ONLINE-ETHERNET / PCL II (or)
ONLINE-ETHERNET / LP+
356351.exe
(Note 4)
Via Network
(Note 1)
4 MB Flash
4 MB DRAM
D printers using
VGL emulation
ONLINE-ETHERNET / LP+ (or)
ONLINE-E-NET / CODE V / PCL
356353.exe
(Note 4)
Via Network
(Note 1)
4 MB Flash
4 MB DRAM
D printers using
PGL emulation
ONLINE-ETHERNET/PGL/LP+ (or)
ONLINE-ETHERNET/PCL-II
356352.exe
(Note 4)
Via Network
(Note 1)
4 MB Flash
4 MB DRAM
NOTES
* ONLINE - SERL / PCL II or ONLINE - SERL / LP PLUS if serial port is the selected host interface
1 If the internal network card is not installed or was removed, download via the parallel or serial port. If the printer
Function Code is downloaded with the LineJet Print Server removed, or a LineJet Print Server is added to the
printer after downloading, the Ethernet port will not function with LineJet Printer Manager. In this case, do the
following:
1. Press the up/down/right/left arrow keys simultaneously. Printer displays “FACTORY / Printer Management.”
2. Press the down arrow key. Printer displays “Diagnostic Port.”
3. Press the down arrow key. Printer displays “Debug Serial.”
4. Press the right arrow key. Printer displays “Debug Ethernet.”
5. Press ENTER. Printer displays “Debug Ethernet*.” Press ONLINE to exit.
2 On an HP3000 MPE host system, if Page Level Recovery functionality is desired, the printer must be upgraded
with the latest Function Code. The printer can be upgraded to the latest Function Code (Model C320xD) if CMX
version 5.5 is present in the printer and 4 MB of Flash and 4 MB of DRAM are installed. “A” model printers may
need a new CMX , 4 MB Flash and 4 MB DRAM. “B” model printers will need 4 MB Flash and 4 MB DRAM.
To upgrade “A” or “B” model Flash memory and DRAM, do the following:
1. Remove the 1 MB Flash (P/N 202554-001) and install a 4 MB Flash (P/N 202417-001) in Bank 0 of the flash
SIMM sockets on the CMX PCA. (This is the flash socket closest to the front of the printer.)
2. “A” and “B” printers were shipped with 2 MB of DRAM (P/N 202502-001) installed in Bank 0 of the DRAM
SIMM sockets. You can add another 2 MB DRAM to the rear DRAM socket on the CMX board, filling both
sockets with 2 + 2 MB DRAM for the required total of 4 MB (the preferred) method), or you can install one 4 MB
SIMM (P/N 202412-001) in Bank 0 of the DRAM SIMM sockets.
3 Upgrade to the latest Function Code (C320xD Function Code).
4 Check with Technical Support to confirm the latest available Function Code download file.
Table 4. LineJet Printer / LP Series Function Code Chart
Model Description
Control Panel Displays:
(Emulation in Use)
Download
File (as
shipped)
Download
Method
Minimum
Flash/DRAM
Required
