NetWare Version 3.x PSERVER Setup
187
7. Select “Print Server Information” and press ENTER.
8. Press INSERT when the list of existing print servers displays.
9. Type the name of the LineJet Print Server when prompted for a print
server name and press ENTER when done. By default, the LineJet Print
Server is named
M_
xxxxxx
where
xxxxxx
equals the last six digits of
the print server Ethernet address found on configuration printouts or
reading MAC address on control panel. (e.g.,
M_071C1A).
10. Back at the print server list, select this newly defined LineJet Print Server
and press ENTER.
11. Select “Print Server Configuration” from the menu that displays.
12. Select “Printer Configuration” from the next menu to display a list of
configured printers.
13. Select the first item listed as “NOT INSTALLED” and press ENTER.
14. At the printer configuration window, type in the name for this new printer.
This name must be one of the pre-defined destinations/queues on the
LineJet Print Server. This will normally be “d1prn.”
15. Go to the “Type” field and press ENTER to see the possible choices.
16. Select “Defined Elsewhere” from this list.
17. When done, press ESCAPE and select “Yes” to save the changes to this
new printer.
18. Press ESCAPE again to return to the Print Server Configuration menu.
19. Select “Queues Serviced by Printer.”
20. Select this new printer from the printer list that displays and press
ENTER.
21. At the empty queue list that displays, press INSERT.
22. Select the queue created in step 5 and press ENTER.
23. When prompted for the priority, press ENTER to select the default or
select a priority.
24. Press ESCAPE until back at the PCONSOLE Main Menu.
25. Repower the printer.
26. Wait two minutes and then select “Print Queue Information” from the
PCONSOLE Main Menu.
27. Select this new queue from the menu that displays. Select “Currently
Attached Servers” to see which print server is servicing this queue.
At this point, the LineJet Print Server name (e.g.,
M_071C1A) should show
within this window. This means the LineJet Print Server knows about this new
Novell print queue it must service as a PSERVER. Therefore, it will poll this
queue regularly looking for jobs to print.
Note The LineJet Print Server can service up to four printers on one file server.
It can not service multiple file servers at one time.
