Administering Telephone Options
104 9600 Series SIP IP Telephones Administrator Guide SIP Release 2.0
Table 14: Impact of TLVs on System Parameter Values
System
Parameter Name
TLV
Name
Impact
PHY2VLAN IEEE 802.1 Port
VLAN ID
System value changed to the Port VLAN identifier in
the TLV.
L2QVLAN and
L2Q
IEEE 802.1 VLAN
Name
The system value is changed to the TLV VLAN
Identifier. L2Q is set to 1 (ON).
A check is made as to whether a reset is necessary
to obtain a new IP address due to a change in the
values of the parameters L2Q or L2QVLAN.
VLAN Name TLV is ignored if:
● the value of USE_DHCP is “0” and the value
of IPADD is not “0.0.0.0”, or
● the current value of L2QVLAN was set by a
TIA LLDP MED Network Policy TLV, or
● the VLAN name in the TLV does not contain
the substring “voice” in lower-case,
upper-case or mixed-case ASCII characters
anywhere in the VLAN Name.
L2Q,
L2QVLANID,
L2QAUD,
L2QSIG,
DSCPAUD,
DSCPSIG
TIA LLDP MED
Network Policy
TLV
L2Q - set to “2” (off) If T (the Tagged Flag) is set to
0; set to “1” (on) if T is set to 1.
L2QVLAN - set to the VLAN ID in the TLV.
L2QAUD and L2QSIG - set to the Layer 2 Priority
value in the TLV.
DSCPAUD and DSCPSIG - set to the DSCP value
in the TLV.
A check is made as to whether a reset is necessary
to obtain a new IP address due to a change in the
values of the parameters L2Q or L2QVLAN.
This TLV is ignored if:
● the value of USE_DHCP is “0” and the value
of IPADD is not “0.0.0.0”, or
● the Application Type is not 1 (Voice), or
● the Unknown Policy Flag (U) is set to 1.
SIPPROXYSRVR Proprietary Call
Server TLV
SIPPROXYSRVR will be set to the IP Address(es)
in this TLV value.
TLSSRVR and
HTTPSRVR
Proprietary File
Server TLV
TLSSRVR and HTTPSRVR will be set to the IP
Address(es) in this TLV value.
