3.6.9 Security Settings - 802.1x
This uses the 802.1x standard for client authentication, and WEP for data encryption. If
possible, you should use WPA-802.1x instead, because WPA encryption is much
stronger than WEP encryption.
If this option is selected:
· This WAP-4060PE must have a "client login" on the Radius Server.
· Each user must have a "user login" on the Radius Server. Normally, a Certifi-
cate is used to authenticate each user.
· Each wireless client must support 802.1x.
· All data transmission is encrypted using the WEP standard. You only have to
select the WEP key size; the WEP key is automatically generated.
Data - 802.1x Screen
802.1x
Radius Server Ad-
dress
Enter the name or IP address of the Radius Server on
your network.
Radius Port
Enter the port number used for connections to the Radius
Server.
Client Login Name
This read-only field displays the current login name, which
is the same as the name of the WAP-4060PE. The Radius
Server must be configured to accept this login.
Shared Key
This is used for the Client Login on the Radius Server.
Enter the key value to match the Radius Server.
