16
Specified
VLAN ID
If selected, you can enter the desired VLAN ID. Normally, this ID
should be one of the client VLAN IDs defined above.
3.6 Configure Security Profile
This screen is displayed when you select a Profile on the Security Profiles screen, and
click the Configure button.
3.6.1 Profile Data
Enter the desired settings for each of the following:
Profile Name
Enter a suitable name for this profile.
SSID
Enter the desired SSID. Each profile must have an unique
SSID.
Wireless Band
Displays the wireless band for this profile.
3.6.2 Security Settings
Select the desired option, and then enter the settings for the selected method.
The available options are:
· None - No security is used. Anyone using the correct SSID can connect to your
network.
· WEP - The 802.11b standard. Data is encrypted before transmission, but the
encryption system is not very strong.
· WPA-PSK - Like WEP, data is encrypted before transmission. WPA is more
secure than WEP, and should be used if possible. The PSK (Pre-shared Key)
must be entered on each Wireless station. The 256Bit encryption key is derived
from the PSK, and changes periodically.
· WPA-802.1x - This version of WPA requires a Radius Server on your LAN to
provide the client authentication according to the 802.1x standard. Data transmis-
sions are encrypted using the WPA standard.
