• Avoid mixing NCQ and non-NCQ commands
Table 2-2: Maximum Sustained Read and Write: MB/sec and IOPS
Access Type
VRFS1xGA
VRFS1xGJ
VRFS1xGK
VRFS1xGM
VRFS1xGF
VRFS1xGN
Units
Sequential Read, 128K block size
Up to 260 Up to 500 Up to 520 MB/s
Sequential Write, 128K block size
Up to 260 Up to 500 Up to 520 MB/s
Random Read, 4K block size
Up to 30,000 Up to 60,000
IOPS
Random Write, 4K block size
Up to 30,000 Up to 20,000
Up to
IOPS
Notes:
1. Performance measured after SSD preconditioning
2. Tested with IOmeter 08 and queue depth (QD) set to 32.
3. Write Cache enabled.
4. Random IOPS (Input/Output Operations per Second) cover the entire range of legal logical block
addresses (LBA’s). Measurements are performed on a full drive (all LBA’s have valid content).
5. Performance may vary by NAND type and host.
6. Refer to Application Note AN0006 for Viking SSD Benchmarking Methodology.
