1.3 SATA Interface for VRFS1xGA, VRFS1xGJ
• The Serial ATA (SATA) interface is compliant with the SATA IO Serial
ATA specification, Revision 2.6 that supports SATA up to 3Gbps.
• The SATA interface connects the host computer to the SSD subsystem.
• The SATA interface runs at a maximum speed of 3 Gbps (Gigabits per
second). If the host computer is unable to negotiate a speed of 3 Gbps,
the SATA interface automatically renegotiates to a speed of 1.5 Gbps.
1.4 SATA Interface for VRFS1xGF, VRFS1xGK, VRFS1xGM
• The Serial ATA (SATA) interface is compliant with the SATA IO Serial
ATA specification, revision 3.x that support SATA up to 6 Gbps.
• The SATA interface connects the host computer to the SSD subsystem.
• The SATA interface runs at a maximum speed of 6.Gbps (Gigabits per
second). If the host computer is unable to negotiate a speed of 6 Gbps,
the SATA interface automatically renegotiates to a speed of 3 or 1.5 Gbps.
For a list of supported commands and other specifics, please see Chapter 5.
2 Product Specifications
2.1 Capacity-LBA
Table 2-1: Capacity and LBA Count
CAPACITY
RAW
CAPACITY
USER
512_LBA_COUNT
15,625,000
