Ports to Open in Firewalls
Default Port Numbers C-3
C.3 Ports to Open in Firewalls
If you plan to install Oracle Application Server behind a firewall, you need to open
certain ports in the firewall during installation and during runtime.
Oracle Management Agent 1157 1157; 18120 -
18139
Oracle Management
Agent port
Application Server Control - RMI 1850 1850-1869,
18140 - 18159
Application Server
Control RMI port
Application Server Control Console - SSL 1156 1156; 1810 -
1829, 18100 -
18119
This port number is assigned
after installation, when you
configure
Application
Server Control for SSL.
See the Oracle Application
Server Administrator’s Guide
for details.
Enterprise Manager Console HTTP port (orcl) 5500 5500 - 5559 Not settable through
staticports.ini
Enterprise Manager Agent port (orcl) 1831 Not settable through
staticports.ini
Log Loader 44000 44000 - 44099
Log Loader port
Oracle Internet Directory
Oracle Internet Directory 389 (but see
the Note on
page 2-10)
389, 13060 -
13129
Oracle Internet Directory
port
Oracle Internet Directory (SSL) 636 (but see
the Note on
page 2-10)
636, 13130 -
13159,
13161-13199
Oracle Internet Directory
(SSL) port
Oracle Application Server Certificate Authority
(OCA)
Server Authentication Virtual Host (SSL) 6600 6600 - 6619
Oracle Certificate
Authority SSL Server
Authentication port
Mutual Authentication Virtual Host (SSL) 6601 6600 - 6619
Oracle Certificate
Authority SSL Mutual
Authentication port
Oracle Application Server Guard
Oracle Application Server Guard 7890 7890-7895
ASG port
OracleAS Metadata Repository
Oracle Net Listener 1521 1521 Not settable through
staticports.ini
Oracle Identity Federation
Oracle Identity Federation -- -- Uses the same port as Oracle
HTTP Server Listener.
Table C–1 (Cont.) Default Port Numbers and Ranges (Grouped by Component)
Component Default Port
Port Number
Range Name in staticports.ini
