C-30HD — PARTS & OPERATION MANUAL — REV. #4 (03/06/01) — PAGE 67
C-30MG — MANIFOLD ASSEMBLY C-30MG
C-30MG CONCRETE PUMP
MANIFOLD ASSEMBLY-C30-MG
NO. PART NO. PART NAME QTY. REMARKS
1 EM14832 PUMPING CYLINDER 1
2 EM14827 MANIFOLD 1
3 EM14824 STEEL BALL, 3-1/4 1
4 EM14422 SQ. SEAL 1
5 EM14823 VALVE SEAT 1
6 EM14822 VALVE HOUSING 1
7 EM803 BALL STOP STUD 3
8 EM618 WASHER, 3/4 6
9 EM968266 NUT, JAM 3/4-16 ....................................... 6 ............. REPLACES EM421
10 EM14833 ADAPTOR 1
11 EM802 RETAINING RING 1
12 EM14829 O-RING 1
13 EM18801 O-RING 1
14 EM14824 STEEL BALL, 3-1/4 1
15 EM14826 INSERT 1
16 EM18801 O-RING 1
17 EM14823 VALVE SEAT 1
18 EM14836 VALVE SEAT ADAPT. 1
19 EM963180 BOLT, 3/4-10X5 ......................................... 1 ............. REPLACES EM131
20 EM968446 NUT, HEX 3/4-10 ....................................... 1 ............. REPLACES EM407
21 EM14832 COMP CYLINDER 1
22 EM14828 REDUCER 1
23 EM135 BOLT, 1/4-20X6 1
24 EM14845 CLAMP ARM 1
25 EM14810 SPRING 1
26 EM14830 O-RING 1
27 EM160 BOLT, 3/8-16X3/4 1
28 EM14829 O-RING 1
29 EM802 RETAINING RING 1
30 EM14833 ADAPTOR 1
31 EM18409 O-RING 6
32 EM618 WASHER, 3/4 6
33 EM968266 NUT, JAM 3/4X16 ...................................... 6 ............. REPLACES EM421
34 EM451 NUT, HEX 1-1/4-12 1
