C-30HD — PARTS & OPERATION MANUAL — REV. #4 (03/06/01) — PAGE 47
C-30HD — COMPENSATOR PISTON ROD
C-30HD CONCRETE PUMP
COMPENSATOR PISTON ROD
NO. PART NO. PART NAME QTY. REMARKS
104 EM18800 PUMPING CYLINDER 1
105 EM968446 NUT, HEX 3/4-10 ........................................................ 4 .................... REPLACES EM407
106 EM14413 FACE PLATE 2
107 EM18409 “O” RING 4
108 EM14412 BUSHING 2
109 EM14411 PISTON CUP 2
110 EM14408 BRONZE RING 2
111 EM14410 RING & FELT HOLDER 2
112 EM16493 FELT RING 2
113 EM20816 “O” RING 2
114 EM903162 BEARING CONE ........................................................ 4 ....................REPLACES EM20815
115 EM916001 LUBE FITTING ........................................................... 2 .................... REPLACES EM16179
116 EM14806 PISTON GUIDE 1
117 EM903163 BEARING CUP ........................................................... 2 ....................REPLACES EM20812
118 EM20814 BUSHING 2
119 EM20813 SPACER 2
120 EM14805 ROD END 1
121 EM14331 BACKING PLATE 1
122 EM14333 RETURN SPRING 1
123 EM14332 GUIDE ROD 1
124 EM14105 ANCHOR PLATE 1
125 EM20412 OILER FITTING MINI-BARB 2
126 EM14409 OILER PLATE 2
127 EM14407 “O” RING 2
128 EM916001 LUBE FITTING ........................................................... 3 .................... REPLACES EM16179
129 EM14336 PISTON GUIDE 1
130 EM14334 COMPENSATOR SPRING 1
131 EM704 PIN, LG SPIRAL 1/2X2 1
132 EM14335 PISTON ROD 1
