C-30HD — PARTS & OPERATION MANUAL — REV. #4 (03/06/01) — PAGE 51
C-30HD — CONNECTING ROD ASSEMBLY 20328T (NEW STYLE)
C-30HD CONCRETE PUMP
CONNECTING ROD ASSEMBLY EM20328T (NEW STYLE)
NO. PART NO. PART NAME QTY. REMARKS
A EM20328T CONNECTING ROD ASSY ........................................ 1 .................... INCLS. ALL ITEMS W/
*
87 EM14808 PISTON ROD WELDMENT 1
88 EM968446 NUT, HEX 3/4-10 ........................................................ 1 .................... REPLACES EM407
89 EM14807 PUMPING CYLINDER 1
90
*
EM20816 O-RING 2
91
*
EM903162 BEARING CONE ........................................................ 2 ....................REPLACES EM20815
92
*
EM20813 SPACER 1
93
*
EM916004 LUBE FITTING ........................................................... 1 .................... REPLACES EM16153
94
*
EM903175 BEARING CUP ........................................................... 1 ....................REPLACES EM20333
95
*
EM20814 BUSHING 1
96
*
EM402996 SPACER ...................................................................... 1 ....................REPLACES EM20335
97
*
EM20336 “O” RING 2
98
*
EM903176 BEARING .................................................................... 1 .................... REPLACES EM20337
99
*
EM916001 LUBE FITTING ........................................................... 1 .................... REPLACES EM16179
100
*
EM20364 CONNECTING ROD 1
101 EM703 SCREW, SET, LG CUP 3/8-16X3/8 1
102 EM702 SCREW, SET, POG POINT 3/8-16X3/8 1
103 EM20338 SPACER 1
