4. Press the down arrow button or the up arrow button to select a component to test.
Table 3-6 Components test
Component test Item Control-panel display
message
Description
Main motor test M8001 DRUM MOTOR Activates the main motor for 10 seconds.
Scanner motor test Not
applicabl
e
LASER SCANNER MOTOR Activates the laser/scanner motor for 10
seconds.
Fuser motor test M8002 FUSER MOTOR Activates the fuser motor for 10 seconds.
Clutch drive test CL1 INT FEED ROLLER CLUTCH Activates the main motor to activate the
paper feeder pickup clutch for 10 seconds.
Ttay 1 (multipurpose tray)
pickup solenoid test
SL1 MP TRAY SOLENOID DRIVE Activates the Tray 1 pickup solenoid for 10
seconds.
Tray 2 pickup solenoid test SL2 TRAY 2 PICKUP SOLENOID Activates the Tray 3 cassette pickup
solenoid for 10 seconds.
Tray 3 pickup solenoid test SL3
1
TRAY 3 PICKUP SOLENOID Activates the Tray 4 cassette pickup
solenoid for 10 seconds.
Tray 4 pickup solenoid test SL3
1
TRAY 4 PICKUP SOLENOID Activates the Tray 2 cassette pickup
solenoid for 10 seconds.
1
Tray 3 and Tray 4 both use a SL3.
5. Press the OK button to start the test.
