Sequence of operation
The DC controller in the engine-control system controls the operational sequences of the printer. The
table below describes durations and operations for each period of a print operation from when the printer
is turned on until the motor stops rotating
Normal sequence of operation
Table 1-1 Sequence of operation
Name Timing Purpose
WAIT From the time the power switch is turned on or the
door is closed until the printer is ready for a print
operation.
Brings the product to printable condition. The product
performs the following during the operation:
●
Detects the print cartridge
STBY (standby) From the end of the WAIT or LSTR period until either
a print command is sent or the power switch is turned
off.
Maintains the product in printable condition.
INTR (initial
rotation)
From the time the print command is received until the
temperature of the fuser unit reaches its targeted
temperature.
Starts up the high-voltage biases, the laser/scanner
and the fuser unit for printing.
PRINT From the end of the INTR period until the last sheet
completes the fuser operation.
Forms the image on the photosensitive drum based
on the VIDEO signals from the formatter. Transfers
and fuses the toner image to the paper.
LSTR (last
rotation)
From the end of the PRINT period until the main motor
stops rotating.
Moves the last printed sheet out of the product.
The product enters the INTR period as the LSTR
period is completed, if the formatter sends another
print command.
