FieldPoint Operating Instructions
FP-PG-522 and cFP-PG-522
Eight-Channel Pulse Generator
with 2 A, 5–30 VDC Sinking Outputs
These operating instructions describe how to install and use the
National Instruments FP-PG-522 and cFP-PG-522 pulse generator
modules (referred to inclusively as the [c]FP-PG-522). For details
on configuring and accessing the [c]FP-PG-522 over a network,
refer to the user manual for the FieldPoint network module you are
using.
Features
The [c]FP-PG-522 is a FieldPoint pulse generator module with the
following features:
• Eight pulse-output channels
• User-powered 2 A, 5–30 VDC sinking outputs
• 1 s, 10 ms, or 100 µs resolution setting, configurable per
channel
• 16-bit on-time and off-time settings
• 100% duty cycle pulse support
• Finite and continuous pulse-generation modes
• Active/Inactive LED indicators
• 2,300 V
rms
transient overvoltage protection
• –40 to 70 °C operation
• Hot swappable
