12. If it is necessary to replace the display inverter, remove the Phillips PM2.5×6.0 screw (1) that
secures the inverter to the display enclosure.
13. Disconnect the display panel cable (2) and the backlight cable (3) from the inverter.
14. Remove the display inverter (4).
NOTE The display inverter is available using spare part number 438530-001.
15. If it is necessary to replace the display panel, remove the four Phillips PM2.5×6.0 screws (1) that
secure the panel to the display enclosure.
16. Remove the display panel (2).
NOTE Display panels are available using the following spare part numbers:
438541-001—14.1-inch WXGA AntiGlare display panel
438540-001—14.0-inch WXGA AntiGlare display panel
44 Chapter 5 Removal and replacement procedures ENWW
