Left-side components
Item Component Function
(1) Vent Enables airflow to cool internal components.
CAUTION To prevent overheating, do not obstruct
vents. Use the computer only on a hard, flat surface. Do
not allow another hard surface, such as an adjoining
optional printer, or a soft surface, such as pillows or thick
rugs or clothing, to block airflow.
NOTE The computer fan starts up automatically to cool
internal components and prevent overheating. It is normal
for the internal fan to cycle on and off during routine
operation.
(2) RJ-11 (modem) jack (select models only) Connects a modem cable.
(3) RJ-45 (network) jack Connects a network cable.
(4) Power connector Connects an AC adapter.
NOTE The HP 500 Notebook PC does not support Smart
AC adapter technology.
(5) External monitor port Connects an optional VGA external monitor or projector.
(6) PC Card slot Supports optional Type I or Type II 32-bit (CardBus) or 16-bit PC
Cards.
(7) USB ports (2) Connect an optional USB device.
(8) PC Card eject button Ejects the PC Card from the PC Card slot.
ENWW Left-side components 9
