Chapter 4: Getting Started with Command Line Interface (CLI)
The Digital Interface enables you to set interface line parameters for the connection between the Tenor CMS
and the line side (i.e, PBX) and trunk side (i.e., PSTN) circuits, such as framing, line code, etc. If a show is
used from a T1 or E1 device for example, 8 digital interfaces may be seen. The user can then navigate to the
particular digital interface by typing Digital Interface 1 through Digital Interface 8 to view or modify settings
for a specific Digital Interface.
Some of the digital interface attributes can be configured from the DigitalInterface CLI option; the most com-
mon attributes are listed in the examples below.
Example
config-DigitalInterface-1# set LineType 1 (1 = E1)
config-DigitalInterface-1# set Law 1 (1 = aLaw)
config-DigitalInterface-1# set LineCode 2 (2 = HDB3)
Switch Protocol
For an ISDN signaling group (PRI signaling group), you must configure the switch protocol. The example
below shows you how to set the protocol to ETSI.
Example
config-ISDNSignalingGroup-1#set Protocol 5 (5 = PRI_ETSI)
Trunk Group
Trunk group configuration are specific parameters you assign for each trunk group. Through the LineCir-
cuitRoutingGroup option, you can set parameters such as the direction of the call type permitted and the num-
ber of digits to be sent to the line side circuit.
Example
config-TrunkCircuitRoutingGroup-1# set Direction 2 (2 = Bi-directional)
config-TrunkCircuitRoutingGroup-1# set PassThroughEnable 1 (1 = Yes)
To attach a hunt LDN directory, there must be one existing already or created and entries are able to be made
into the directory.
Example
config-LineCircuitRoutingGroup-1# new hldnd 1Id (creates a Hunt LDN directory with ID = 1Id)
config-HuntLDNDirectory-1# add 3094* (adds entry to Hunt LDN directory)
