www.pridemobility.com Quantum Jazzy 1400 Series Rev D May 04
SPECIFICATIONS
Suspension: Active-Trac Suspension with Rear Suspension
Drive Wheels: 1420 - 16 in., pneumatic, center-mounted (solid tires are optional)
1400 - 14 in., pneumatic, center-mounted (solid tires are optional)
Caster Wheels: 1420 - 9 in., pneumatic, rear articulating (solid tires are optional)
1400 - 8 in., solid, rear articulating
Anti-tip Wheels: 1420 - 8 in., solid, front mounted
1400 - 6 in., solid, front mounted
Maximum Speed: Up to 4.5 mph (up to 6 mph with hi-speed motors)
Brakes: Intelligent Braking, electronic regenerative, disc park brake
Ground Clearance: 1420 - 4.5 in.
1400 - 3 in.
Turning Radius: 22.5 in. (1420), 21.5 (1400)
Overall Size: Length: 45.5 in. (1420), 40.5 in. (1400)
Width: 26.75 (1420), 25.4 in. (1400)
Seating Options: Synergy Seat (standard)
TRU-Balance (optional)
Medium Back Seat (optional)
High Back Seat (optional)
Reclining Seat (optional)
Power Elevating (optional)
Drivetrain: Two motor, mid-wheel drive
Batteries: Two 12-volt, Group 24 batteries
Two 12-volt, NF-22 batteries (Power Elevating Seat Option)
Range: Up to 25 miles
Battery Charger: 5-amp, Onboard (standard)
5-amp, Off-board
Electronics: 70-amp PG Remote Plus Controller
70-amp Dynamic Europa Remote Controller
Weight Capacity: 1420 - 500 lbs.(425 lbs. with hi-speed motors/400 lbs. with TRU-Balance)
1400 - 400 lbs.(325 lbs. with hi-speed motors)
Component Weights: Base: 136 lbs. (1420), 128 lbs. (1400)
Seat: 44 lbs.
Batteries: 53.5 lbs. each
IV. THE QUANTUM JAZZY 1400 SERIES
