35
Hurricane www.pridemobility.com
X. BASIC TROUBLESHOOTING
What if all the systems on my PMV seem to be “dead”?
! Make certain that the key is in the “on” position.
! Check that the batteries are fully charged.
! Push in the main circuit breaker reset button. See V. “Your PMV.”
! Make certain that both T-handle battery harnesses are firmly connected to the rear section and to the battery
terminals. See IX. “Disassembly and Assembly.”
! Make sure that the front-to-rear harness is firmly connected to the rear section. See IX. “Disassembly and
Assembly.”
! Be sure the power down timer feature hasn’t been activated. See VII. “Operation.”
! Check the 3-amp fuse located on the lower portion of the tiller console. See XI. “Care and Maintenance” for
fuse replacement.
What if my PMV does not move when I engage the throttle control lever?
! When the manual freewheel lever is pushed forward, the brakes are disengaged and all power to the motor/
transaxle assembly is cut.
! Pull back on the manual freewheel lever, turn the PMV off, then back on to return to normal operation.
DIAGNOSTIC FLASH CODES
The diagnostic flash codes for your PMV are designed to help you perform basic troubleshooting quickly and
easily. A diagnostic flash code will flash from the status LED in the event one of the conditions listed below
develops.
NOTE: Your PMV will not run unless the flash code condition is resolved and the PMV has been
turned off, then turned back on.
Any electromechanical device occasionally requires some troubleshooting. However, most of the problems that
may arise can usually be solved with a bit of thought and common sense. Many of these problems occur because
the batteries are not fully charged or because the batteries are worn down and can no longer hold a charge.
FLASH CODE CONDITION SOLUTION
(1)
!
Battery voltage is too low to operate the
PMV.
Check connections between batteries and
controller.
(2)
!!
Motor disconnected. Check all connections to the motor.
(3)
!!!
Motor wiring fault. Call your authorized Pride Provider for assistance.
(6)
!!!!!!
PMV won’t operate because the charger
is attached.
Unplug the charger power cord from the off-board
charger port.
(7)
!!!!!!!
Throttle potentiometer fault. Call your authorized Pride Provider for assistance.
(8)
!!!!!!!!
Internal controller fault. Call your authorized Pride Provider for assistance.
(9)
!!!!!!!!!
Brake fault—your PMV was left in
freewheel mode.
Turn the PMV key to the “off” position, then push
the manual freewheel lever to the drive position,
and restart your PMV.
(10)
!!!!!!!!!!
Excess voltage to controller.
Check all connections between the batteries and
the controller. If condition persists, contact your
authorized Pride Provider for assistance.
