MODEL
PRODUCT
WEIGHT
OPERATING
GALLONAGE
TOTAL WEIGHT/
FLOOR LOADING
SPECIFICATIONS (Corner)
DIMENSIONS
DRAIN/OVERFLOW
DIMENSIONS
SKIRT &
MOUNTING
CUTOUT
HEATER READY
FOR FIELD
INSTALLATION
CORNER BATHS
DRAIN/OVERFLOW
A
B
ESPREE 6060
60" (1524 mm) L
60" (1524 mm) L
22" ( 559 mm) H
888 lb
(404 k/g)/
36 lb/sq. ft.
(176 kg/sq. m)
122 lb
(55 kg)
18-1/2" (470 mm) A
12-1/4" (311 mm) B
See
Page 4
Not Available
Factory Installed
(S750000 HEATER KIT)
ESPREE 6060
2"
51 mm
H
FRONT VIEW
SIDE VIEW
ESPREE 6060
WITH INTEGRAL
SKIRT
60" (1524 mm) L
60" (1524 mm) L
22" ( 559 mm) H
888 lb
(404 k/g)/
36 lb/sq. ft.
(176 kg/sq. m)
122 lb
(55 kg)
18-1/2" (470 mm) A
12-1/4" (311 mm) B
NA
Integral
Factory Installed
(U395000 HEATER KIT)
ESPREE 6060 WITH SKIRT
1"
25 mm
H
FRONT VIEW
SIDE VIEW
SPECIFICATIONS
Lamp Package 7701XXX
959 White
958 Almond
969 Oyster
Jet Trim Kit X163XXX
805 Platinum
815 Satin Nickel
826 Brushed Nickel
827 Chrome
829 PVD Brass
898 Brushed Chrome
845 Oil Rubbed Bronze
Rotary Drain/Overflow
Kit 8730XXX
805 Platinum
815 Satin Nickel
826 Brushed Nickel
827 Chrome
829 PVD Brass
898 Brushed Chrome
845 Oil Rubbed Bronze
RapidHeat™ In Line Heater
Suction Side S750000
Discharge Side U395000
OPTIONS FOR ALL UNITS
NOTE: The overall dimensions are nominal with a tolerance of +0 and -1/4".
FOR ALL UNITS: Electrical Service Requirements: All require a dedicated GFCI protected separate circuit.
RapidHeat: 115 VAC, 15 AMP, 60 Hz. dedicated GFCI protected separate circuit.
Motor/Pump: 115 VAC, 15 Amp, 60 Hz. dedicated GFCI protected separate circuit.
68 Min U.S. gal
(257 liters)
89 Max U.S. gal
(336 liters)
68 Min U.S. gal
(257 liters)
89 Max U.S. gal
(336 liters)
2
Jacuzzi Whirlpool Bath© U961000F 12/04
