RapidHeat Operation
Once the heater is installed and the whirlpool pump
is operating, the heating function is totally automatic.
The heater will help maintain the temperature of the
water in the bath.
Vacuum Switch
The heater is equipped with a preset vacuum switch
which will not allow the heater to turn ON if the pump is
not running with water flowing through the whirlpool
system.
High-Limit Switch
The heater includes an exclusive High-Limit switch.
This safety circuit will not false trip from hot tap water. It
will only turn off the heater if the thermostat fails. To
reset, press the button. If the high-limit trips frequently,
contact your dealer.
Heater On Indicator
The light will be illuminated any time the heater is
operating
Controlling Whirlpool Action
The whirlpool action in your bath is influenced by three
factors – direction of flow, force of water, and force of
air. All baths manufactured by Jacuzzi Whirlpool Bath
are equipped with fully adjustable PowerPro
®
jets, which
are adjustable for all three factors. Some baths have
additional directionally adjustable jets which can be
adjusted for direction and flow of air only.
Direction: To change the direction of the water flow,
swivel the jet nozzle to the desired angle. The jets can
be directed individually toward any location on your body
to provide a hydromassage. The jets can also be ad-
justed so that they all point in the same direction (clock-
wise or counterclockwise) to circulate the water in a cir-
cular motion around the bath, causing a total whirlpool
effect.
DIRECTIONALLY
ADJUSTABLE
FULLY
ADJUSTABLE
JETS
TURN CLOCKWISE TO
REDUCE AIR FLOW
TURN COUNTER-CLOCKWISE
TO INCREASE AIR FLOW
AIR INDUCTION CONTROLS
Water Force: The high volume, fully adjustable jets
can be adjusted to control the force of the water coming
into the bath. For robust action, increase the force of
the flow by rotating the jet handles to the left (counter-
clockwise). For a more gentle effect, rotate the handles
to the right (clockwise). Never run the whirlpool sys-
tem with all the jets closed.
Force of Air: Two knobs located on the bath serve
as controls for the air induction system. The intensity of
the hydromassage whirlpool action is determined by the
amount of air inducted into the water. As the amount of
air is increased, the hydromassage action increases.
For maximum air induction, rotate the control knobs fully
counterclockwise to the largest circles. For fewer air
bubbles, decrease the amount of air induction by rotat-
ing the control knob clockwise. When the knobs are
turned to the smallest circles, only water is being
circulated.
OPERATION
PUSH TO RESET
OVER HEAT
PROTECTION
HIGH LIMIT RESET
HEATER ON
HEATER ON
Back Massage Jet - Flow Adjustment
Open
Close
10
Jacuzzi Whirlpool Bath© U961000F 12/04
