SECTION 4—OPERATION

Invacare Mobile Recliners 18 Part No. 1141494

Locking/Unlocking the Rear Wheels

NOTE:Forthisprocedure,refertoFIGURE 4.6.

1. Pushdownonthewheellockmechanismtoengagethewheellocks.

2. Releasethewheellocksbypushingtheothersideofthelockmechanismdownward.

FIGURE 4.6 Locking/Unlocking the Rear Wheels

Installing/Storing the Tray

Model IH6074A

NOTE:Forthisprocedure,refertoFIGURE 4.7.

NOTE:Reversethisproceduretoremovethetray.

1. Pulldownontheplungerreleaseknobsonbotharmsandtwistthem¼‐turntolock

themintheopenposition.

2. Pullthetrayforwardandclearfromthehangerlocatedonthesideoftherecliner.

3. Alignthealignmentrodswiththemountingbracketsunderthearmrestsofthe

recliner.

4. Insertthealignmentrodsintothemountingbrackets.

5. Slidethetraytothedesiredpositionuntilanaudbileclickisheard.

FIGURE 4.7 Installing/Storing the Tray - Model IH6074A

Locking

Unlocking

Wheel Lock

Mechanism

Wheel Lock

Mechanism

Plunger

Release Knob

Tray

Hanger

Tray

Mounting

Bracket

Mounting Bracket

(Hidden from View)

Armrest

Armrest

Alignment Rods

Alignment Rod

Alignment Rod

DETAIL “B” - SIDE VIEW

DETAIL “A” - FRONT VIEW
