SECTION 4—OPERATION

Invacare Mobile Recliners 16 Part No. 1141494

Assisted Recline

NOTE:Forthisprocedure,referto

FIGURE 4.2.

1. Swingreclinelockbaruptochairback

andlockintoposition.

2. Graspthearmrestwithonehandand

thepushbarwiththeotherhand.

3. Pushthebackofthechairdownslowly

untiladesiredpositionisreached.

NOTE:Thecaregivercansetreclinelockbarat

oneofthethreelockingpositions.

FIGURE 4.2 Reclining the Chair - Models

IH6074A and IH6065 series - Assisted Recline

Model IH6077A

NOTE:ThepositionlockleverisnotavailableonmodelIH6077A.

User Recline

NOTE:Forthisprocedure,refertoFIGURE 4.3.

1. Whileseatedintherecliner,gripthearmrestsandsimultaneouslyleanbodyweight

backandpushforwardwithyourarmsuntilareclinepositionisreached.

NOTE:Thefootrestassemblywillelevateautomaticallyasthechairisreclined.

NOTE:Theoccupantshouldnotberequiredtoexertexcessiveforcetochangereclinepositions.If

thereclinerexhibitsdifficultyinreclining,anattendantshouldbecalledforassistance.

FIGURE 4.3 Reclining the Chair - Model IH6077A - User Recline

Back

Assembly

Storage

Position

Position

Lock Lever
