Bench Receiving Scale
4
Supplying Power to
the Scale
Power can be supplied to the scale through the AC adapter
or optional batteries. The scale uses four (4) D-cell batteries
not supplied by Hobart.
To insert batteries:
1. Open the front cover of the display by pulling the tab
(located on the back right side of the display) toward
you.
Tab
Mating
Terminal
2. Insert batteries using the imprinted diagram inside the
battery case located on the inside front cover of the
display head.
To use the power supply:
1. Connect the wall-mount adapter plug to a 120 V,
60 Hz, 1 Ph electrical outlet.
2. Connect the small, round 12V DC connector to the
Mating Terminal (located on the left lower back corner of
the display head).
☛ Note
When the scale is turned ON, all segments of the display
flash approximately 5 times. Then, zero displays and the
following indicators illuminate.
¥ Zero
¥ Stable
¥ kg
-- OR -- lb
¥ Gross Wt.
