ASSEMBLY INSTRUCTIONS
Ramp - Moving Instructions
1. Remove the guardrail at the end of the platform by unscrewing 4 screws. (see Figure 3)
2. Fold the ramp on the platform surface.
3. Gently tip the scale over and place with handrail on the floor.
4. Remove the screws attaching 2 rubber bumpers on the side of the platform under the
ramp attachment. Remove the bumpers. Install the rubber bumpers on the opposite
platform side in the appropriate holes.
5. Release 4 screws at each ramp holder (2 screws at ramp side and 2 screws at the bottom
of the ramp, close to wheel).
6. Remove the ramp from the ramp holders, then release all the screws to the end and
remove ramp holders by pulling out slightly.
7. Install ramp holders in the same way at the opposite side of the platform, do not tighten
screws.
8. Insert the ramp between ramp holders and tighten screws.
9. Install the guardrail by screwing 4 screws. Note: It is necessary to bore a hole in the mat to
insert the screw in appropriate hole beneath the mat.
Figure 3. Ramp Moving
(refer to the Parts List on page 23 for details on parts followed by
#
)
NOTE
: A second Ramp is available separately as 2600RAMP.
