Press “SET” to continue.
S
Save new setting
8.6.4 Program Function Mode
The next parameter is the program function or cycle mode. There are four pos
-
sible modes which determine whether the program will scan up (from set-point
1 to n) only or both up and down (from set-point n to 1), and also whether the
program will stop after one cycle or repeat the cycle indefinitely. The table be
-
low shows the action of each of the four program mode settings.
Function Action
1up-stop
2 up-down-stop
3 up-repeat
4 up-down-repeat
Pf=1
Program mode
Use the “UP” or “DOWN” buttons to change the mode.
Pf=4
New mode
Press “SET” to continue.
S
Save new setting
8.6.5 Program Control
The final parameter in the program menu is the control parameter. You may
choose between three options to either start the program from the beginning,
continue the program from where it was when it was stopped, or stop the
program.
Pr=OFF
Program presently off
Use the “UP” or “DOWN” buttons to change the status.
Pr=StArt
Start cycle from beginning
Press “SET” to activate the new program control command and return to the
temperature display.
9105/9107 33
8 Controller Operation
