Citizen ch607 Blood Pressure Monitor User Manual



- Eng 14 -
SPECIFICATIONS
Model Number CH607
Measuring Principle Oscillometric System
Measurement Localization Left Wrist Arm
Cuff Preformed cuff
Arm Circumference Range 13.5 to 19.5 cm
Measurement Range
Pressure 0 - 300 mmHg
Pulse 40 - 199 Pulse / Min.
Accuracy
Pressure ±3mmHg
Pulse ±5% of reading
Pressure
Systolic Blood Pressure: 3 digits
Diastolic Blood Pressure: 3 digits
Alternatively
Pulse Pulse Rate: 3 digits
LCD Indication Measuring
Marks
Exhaust
Re-Measure
Battery
LCD
Viewing Size 38.0(H) × 32.0(W) mm
Digit Size 9.5(H) × 5.0(W) mm
Switch 4-switches (Start/Stop, Memory, Set, Mode)
Inflation Automatic Inflation by Air Pump
Deflation Automatic Air release control valve
Exhaust Quick Exhaust Valve
Rated Voltage 3 V DC
Power Source 2 AAA Size Batteries
Power Consumption 0.1 W
Battery Life Approx. 250 times measurement
Automatic Power Off Function Approx. 3 min. (after activated)
Clock Function ±20 Seconds a month, Full Automatic Calendar, Alarm
Memory Function 99 Memory (Date, Time, Blood pressure value, Pulse)
Dimensions 72(W) × 70(D) × 29(H)mm
Weight Approx. 140g including batteries.
Operating Environment
Temperature 10 to 40°C
Humidity 30 to 85%RH
Storage Environment
Temperature 20 to 50°C
Humidity 10 to 95%RH
Accessories 2 AAA batteries, Instruction manual and Carrying case
* Specifications and design may be changed without any notice in the event of improvementsbeing made.
