- Eng 12 -
SPECIFICATIONS
Model No. CH-432B
Measuring Principle Oscillometric Method
Measurement Localization Left Upper Arm
Cuff Soft Cuff
Arm Circumference Range 22.0 to 32.0cm
Measurement Range
Pressure 0 to 280 mmHg
Pulse 40 to 180 Pulse/min.
Accuracy
Pressure ±3 mmHg
Pulse ±5% of Reading
Pressure
Systolic blood pressure: 3 Digits
Diastolic blood pressure: 3 Digits
Alternately
LCD Indication Pulse Pulse rate: 3 Digits
Marks
Measuring
Q
Battery Empty
LCD
View Size 18(H) × 61(W)mm
Digit Size (Pressure) 14(H) × 6.5(W)mm
Switch POWER / START switch
Inflation Automatic Inflation by Internal Pump
Deflation Automatic Air-release Valve
Exhaust Electromagnetic Valve
Rated Voltage 6 VDC
Power Source 4 “AA” Size Batteries
Power Consumption 4W (Measuring)
Battery Life
Manganese Batteries Approx. 200 times
(160 mmHg, 1 time/day, 22°C)
Alkaline Batteries Approx. 700 times
Automatic Power-Off Function Approx. 3 min.
Memory Function 1 Memory
Dimension 129(W) × 121.5(D) × 55(T) [mm]
Weight Approx. 300g
Operating Environment
Temperature 10 to 40°C
Humidity 30 to 85%RH
Storage Environment
Temperature –20 to 60°C
Humidity 10 to 95%RH
* Specifications and designs may be changed without notice in the event of improvements being made.
