SPECIFICATIONS
POWER & MEASURE 2-WIRE TRANSMITTERS
RANGES & ACCURACY: Same as for MILLIAMP SOURCE
OUTPUT CURRENT: up to 24.00 mA
TYPICAL DRIVE CAPABILITY:1200 Ohms @ 20.00 mA
COMPLIANCE VOLTAGE: nominal 25 VDC @ 20 mA
COMMON MODE ERROR: 0.01% Full Scale/Common Mode Volt
2-WIRE TRANSMITTER SIMULATOR
RANGES:
1.00 to 24.00 mA; -18.8 to 125.0% of 4 to 20 mA; % DP Flow
ACCURACY: Same as for MILLIAMP SOURCE
LOOP VOLTAGE LIMITS: Mininum, 3 VDC; Maximum 45 VDC
OVERLOAD PROTECTION: Current limited to 25 mA nominal
COMMON MODE ERROR: 0.01% Full Scale/Common Mode Volt
MILLIAMP READ
RANGES:
0.00 to 24.00 mA; -25.0 to 125.0 % of 4 to 20 mA; % DP Flow
ACCURACY: Same as for MILLIAMP SOURCE
OVERLOAD PROTECTION: Current limited to 25 mA nominal
VOLTAGE BURDEN: 0.9V at 4 mA, 1.2V at 20 mA, 1.9V at 24 mA
DC VOLTAGE SOURCE
RANGES: 0.00 to 110.00 mV; 0.00 to 10.25V
ACCURACY:
±(0.05% of 110 mV+ 0.01mV) = ±0.07 mV
±(0.05% of 10.25 V + 0.01V) = ±0.02V
SOURCE CURRENT: >20 mA
SINK CURRENT: >20 mA
OUTPUT IMPEDANCE: <0.3 Ohms
SHORT CIRCUIT DURATION: Infinite
MEASURE AC VOLTS
RANGE: 0.0 to 250.0 V True RMS
ACCURACY:From 10 to 250 VAC ±(2% of 250 V + 0.1 VAC) = ±5.1 VAC
MAXIMUM CREST FACTOR: < 3
FREQUENCY RANGE: 45 to 800 Hz
36
SPECIFICATIONS
GENERAL
TYPICAL 90 DAY ACCURACY: ±(0.025% of Full Scale + 1 LSD)
1
1 YEAR ACCURACY: ±(0.05% of Full Scale + 1 LSD)
WARM UP TIME: 10 seconds to specified accuracy, 2 minutes to
maximum accuracy
TEMPERATURE EFFECT: ±0.01% per °C based on 23°±25°C
BATTERIES: Six “AA”, (R6) batteries (Alkaline supplied and
recommended)
BATTERY LIFE:
MILLIAMP SOURCE & 2-WIRE MODES: Nominal 12 hours at
20 mA with 250Ω load; OTHER FUNCTIONS: Nominal 50 hours
Note: Battery life is reduced when LCD backlighting is on
LOW BATTERY INDICATION: “BAT” indication on the display at
approximately 4 hours left
OVERLOAD PROTECTION: Three fuses, 125 mA
NOISE: ±1 LSD at frequencies less than 10 Hz
NORMAL MODE REJECTION RATIO: 50 dB @ 50/60 Hz
OPERATING TEMPERATURE RANGE: -5 to +130 °F (-20 to +55°C)
STORAGE TEMPERATURE RANGE: -13 to +130°F (-25 to +55°C)
RELATIVE HUMIDITY: 10 to 90%, non-condensing for 24 hours
from 0 to 35°C
OVERALL SIZE: 158.1 x 83.1 x 49.3 mm (6.23 x 3.27 x 1.94”)
WEIGHT: 0.6 kg (1 lb, 5 oz)
MILLIAMP SOURCE
RANGES:
0.00 to 24.00 mA; -25.0 to 125.0 % of 4 to 20 mA; % DP Flow
ACCURACY: ±(0.05% of 24 mASpan + 0.01 mA) = 0.02mA
TYPICAL DRIVE CAPABILITY: 1200 Ohms @ 20.00 mA
COMPLIANCE VOLTAGE: nominal 25 V @ 20 mA
1
Typical 90 day accuracy can be estimated by dividing the 1 year
% of full scale accuracy by 2. Additions to the specification, such
as + 1 LSD, remain constant
Specifications subject to change without notice
