MYS Player – Main Window (cont …)
28
MYS Player – Main Window (cont …)
1. MYS PLAYER MENU CONTROLS – The Menu Controls operate in the same way as the PC Viewer
Controls (see above).
2. VIDEO DISPLAY – Displays the Video in Single, 2-Channel or Quad View. The video is displayed in
Quad view when the application loads.
3. CHANNEL TITLE & DATE – Displays the Channel Description (CH1 ~ CH4), and the Date and Time
of the Recorded Video.
4. MYS PLAYER BUTTON
– Returns to the PC Viewer Application Window (see above).
5. OPEN VIDEO BUTTON
– Used to select a different MYS Video File.
6. FILE DETAILS – Displays the MYS Video File Name and File
Size (in MB).
7. MYS PLAYBACK CONTROLS – Controls the playback of the current
onscreen Video (Reverse Playback, Step-Reverse Single Frame,
Pause/Play, Step-Forward Single Frame and Fast Forward).
8. CAPTURE JPEG STILL IMAGE – Saves the current video image as a JPEG Image file.
• Load the Video into the Player Window.
• Use the Viewer Controls to locate the point in the video to start the Image Save.
• Press the PAUSE button on the Viewer Controls
• Press the Capture JPEG Image
button.
• A ‘Screen Capture Message’
window will appear indicating a
successful image capture.
9. AUDIO CONTROLS – Controls the Audio Playback Volume and Mute Status.
NOTE: If no audio capture device has been connected to the DVR, audio will not be
recorded to the DVR.
10. PLAYBACK STATUS – Indicates the current Video Playback status as
PLAYING or PAUSE.
