4-6 Replaceable Parts HP OmniBook 4100/4150
Description Part Number Exchange User- OmniBook
Part Number Repl. 4150B 4150† 4100
48 Plate, CPU top (2-screw), Pentium II (MD) F1460-60950
••
48 Plate, CPU top (5-screw), Pentium II (MD, D) F1640-80002
•
RAM module (see table on page 4-9)
Screw, M2×3mm F1440-60988
•
49 Screw, M2×3.5mm F1640-60912
•••
50 Screw, M2×4mm F1460-60989
•••
61 Screw, M2×5mm F1640-60913
••
63 Screw, M2×12mm F1440-60981
•
51 Screw, M2×14mm F1460-60988
••
52 Screw, M2.5×4mm F1460-60990
•••
53 Screw, M2.5×5mm F1460-60984
•••
54 Screw, M2.5×16mm F1460-60986
•••
55 Screw, M2.5×19mm F1460-60985
•••
57 Screw, M3×4mm F1629-60911
•••
64 Screw/spring, M2 (CPU) F1660-60914
•
58 Socket, PCMCIA F1460-60919
•••
Spacer, CPU Pentium II (MD) F1462-80003
•
Spacer, LCD connector (all 13") F1462-60925
••
Spacer, top plate F1460-80018
•
Spacer, VGA PCA (rubber) F1640-60944
•
Spacer kit, for 8.4mm HDD (top and end) F1629-60933 Yes
•••
Spacer, for 9.5mm HDD (top) F1629-60934 Yes
•••
59 Speaker F1460-60960
•••
62 Spring, display ground F1462-60928
•••
60 Standoff, VGA F1440-60976
•••
Tape, Kapton, 0.75” x 36 yards F1391-60963
•••
Thermal pad, CPU notched (T, MD) 5182-5153
••
Thermal pad, large Pentium (T) F1463-80001
•
Thermal pad, medium Pentium (T) F1463-80002
•
Thermal pad, small Pentium (T) F1463-80003
•
Thermal pad, square Pentium II (MD) F1462-80004
••
Thermal pad, notched (heatsink, top plate) F1640-60911
••
*See
Table 4-2 for components.
** These hard drives are the preferred drives at the time of publication. Drives shipped in units are subject to
change without notice. For current information about preferred and approved drives for these products, see
the latest version of service note HDD-01.
*** For serial numbers below TW85299999, use F1629-69001. For serial numbers above TW90100000, use
F1640-69001.
