HP OmniBook 4100/4150 Removal and Replacement 2-13
Removing the LCD Module
(HP Authorized Service Providers Only)
Note
The exact details for removing the LCD module depend on the type of module. Some details may
differ from those described in this section.
See the table below for information about matching components for different types of LCD
modules.
Table 2-7. Display Component Compatibility
LCD Type* 13"Samsung 14" LG 14" IBM74* 14" IBM74E*
OmniBook Model 4100 4100 4150† 4100 4150† 4150†
Bezel, display
F1460-60969 F1460-60967 F1629-60909 F1462-60927 F1629-60919 or F1660-60911
Cable, LCD flex
F1460-60975 F1460-60981 F1629-60915
Cable, LED strip
F1460-60972 F1629-60916
Case, display
F1460-60970 F1460-60968
Kit, display case (latch...)
F1460-60971
Kit, LCD (brackets, shield...)
F1460-60974 F1460-60980 F1629-60932 F1640-60909
LCD module
F1460-69098 F1440-69095 F1629-69012 F1640-69008
PCA, inverter
F1460-60917 F1460-60918 F1629-60908 F1629-60917
PCA, LVDS
F1460-60914 F1460-60916 F1629-60907 F1462-60926 F1629-60918
PCA, VGA
F1460-60906 F1629-60903 F1460-60906 F1629-60903
LCD Type* 13" Hyundai 14" LG* 14" IBM74E 14" IBM76* 14" CPT
OmniBook Model 4150B 4150B 4150B 4150B 4150B
Bezel, display
F1655-60915 F1660-60911
Cable, LCD flex
F1660-60922 F1660-60913 F1660-60921 F1660-60913 F1660-60920
Cable, LED strip
F1629-60916
Case, display
F1460-60970 F1460-60968
Kit, display case (latch...)
F1460-60971
Kit, LCD (brackets, shield...)
F1660-60919 F1660-60915 F1640-60909 F1660-60915 F1660-60918
LCD module
F1655-69020 F1660-69029 F1640-69008 F1660-69028 F1660-69030
PCA, inverter
F1460-60917 F1660-60912 F1660-60924 F1660-60912
PCA, LVDS
(none) (none) (none) (none) (none)
PCA, VGA
(with switch settings)
F1660-60908
4 —
3 — 0
2 — F
1 — F
F1660-60908
4 —
3 — 0
2 — F
1 — F
F1660-60908
4 —
3 — 0
2 — F
1 — F
F1660-60908
4 —
3 — 0
2 — F
1 — F
F1660-60908
4 —
3 — 0
2 — F
1 — F
* To identify the type of LCD module, see the marking printed on the LCD flex cable where it plugs into the
base—it may be on the top or bottom of the cable.
For an OmniBook 4150B with an LG or IBM76 LCD module, if the marking on the cable is not certain,
see the switch settings on the VGA PCA to identify the module.
For an OmniBook 4150† with an IBM LCD module, the IBM74 has a shield with a solid back, and the
IBM74E has a shield with a mylar-covered opening across the back.
† Models called 4150† in this manual have no marking in the serial number, whereas models called 4150B
have 4150 B after the serial number.
