administrator.
o location ASCII-STR - Up to 48 characters. Description of the
switch location.
o community ASCII-STR - Enter up to 32 characters to name an SNMP
community.
o <manager|operator> - manager - the community can access all MIB
objects; operator (default) - the community can access all except
the CONFIG MIB.
o <restricted|unrestricted> - unrestricted - any MIB variable that
has read/write access can be set; restricted (default) - MIB
variables cannot be set, only read.
o IP-ADDR - Address of the network management station.
o [none|all|not-info|critical|debug] - The level of Switch
events that will generate a Trap to be sent: none - send no log
message; all - send all log messages; not-info - send each log
message that is not informational-only; critical - send
critical-level log messages; debug (reserved for Internal use).
o [IP-ADDR|loopback<0-7>|dst-ip-of-request] - Policy type used to
ll the source-ip address eld of the snmp response/trap pdu:
IP-ADDR - This ip address will be used while sending the
snmp response/trap pdu; loopback<0-7> - lexicographically min.
congured ip address on specied loopback interface will be
used while sending the response; dst-ip-of-request - destination
ip address passed in the request pdu will be send as the source-ip
address in the response pdu.
COMMAND STRUCTURE
■ [no] snmp-server community -- Add/delete SNMP community (ASCII-STR) (p. 615)
■ view < Operator | Manager > -- Add/delete SNMP community (p. 622)
■ write-access < Restricted | Unrestricted | | ... > -- Add/delete SNMP community (p. 622)
■ snmp-server contact -- Name of the switch administrator. (ASCII-STR) (p. 616)
■ [no] snmp-server enable -- Enable/Disable SNMPv1/v2 (p. 616)
■ traps -- Enable/disable event traps to be sent by the switch (p. 621)
■ arp-protect -- Traps for Dynamic ARP Protection. (p. 615)
■ auth-server-fail -- Traps reporting authentication server unreachable. (p. 615)
■ dhcp-snooping -- Traps for DHCP-Snooping. (p. 616)
■ dyn-ip-lockdown -- Traps for Dynamic Ip Lockdown (p. 616)
■ link-change -- Traps for link-up and link-down. ([ethernet] PORT-LIST) (p. 618)
■ login-failure-mgr -- Traps for management interface login failure. (p. 619)
■ password-change-mgr -- Traps for management interface password change. (p. 619)
■ port-security -- Traps for port access authentication failure. (p. 619)
■ snmp-authentication -- Select RFC-1157 (standard) or HP-ICF-SNMP (extended) traps. (p.
620)
■ extended -- Send traps for Extended Authentication failures. (p. 617)
■ standard -- Send traps for Standard Authentication failures. (p. 620)
■ [no] snmp-server host -- Define SNMP traps and their receivers (p. 617)
■ address -- IP address of SNMP notification host. (IP-ADDR) (p. 614)
■ community -- Name of the SNMP community (up to 32 characters). (ASCII-STR) (p. 615)
■ events < None | Debug | All | ... > -- (p. 616)
