Installation
2-10
The Reset Switch
The Reset switch is located under the top plastic tab, as shown in Figure 2-6. Use
the reset switch to reset the moduleÕs processor, shutdown (power down) the
module, and/or restart the module.
¥ To reset the moduleÕs i960 processor, press the reset switch twice within three
seconds.
¥ To shut down the module, press and hold the reset switch for three or more
seconds.
¥ To restart the module, press the reset switch momentarily.
SNMP management may be used to disable this switch to enhance module
security.
Figure 2-6. The Reset Switch
SMB
CPU
Reset Switch
