Installation
2-6
3. Use a Phillips screwdriver to remove the screws and set the screws aside.
4. Carefully grasp the daughterboard and lift up.
5. Turn the daughterboard over to reveal the user-accessible components
illustrated in Figure 2-4.
Figure 2-4. User-Accessible Components on Underside of 9G421-02/9G429-02 Daughterboard
DIP Switch
BOOT PROM
SMB-1 PROM
DRAM SIMM slot
FLASH SIMM slot
