27Jazzy 1103
VI. CARE AND MAINTENANCE
CORRECTIVE MAINTENANCE
If the battery indicator gauge does not light up:
l Check the harness connections. Make sure they are tight.
l Check the circuit breaker. Reset it if necessary.
l Check the battery connections.
If the above conditions prove normal, you can load test the batteries with a battery load tester. These testers are
available at automotive parts stores. Disconnect both batteries before load testing and follow the directions that
come with the load tester. If either one of the batteries fails the load test, replace both of them. If your Jazzy still
does not power up, contact your local Pride provider.
WHEN TO SEE YOUR PRIDE PROVIDER FOR SERVICE
The following symptoms could indicate a serious problem with your Jazzy. If necessary, contact an authorized
Pride provider. When calling, have the model number, serial number, nature of the problem, and the trouble code
if available.
l motor noise
l frayed harnesses
l cracked or broken connectors
l uneven wear on any of the tyres
l jerky motion
l pulling to one side
l bent or broken wheel assemblies
l does not power up
l powers up, but does not move
FIGURE 13. Motor Brush Caps
FIGURE 14. Motor Brushes
WORN MOTOR BRUSH
NEW MOTOR BRUSHES
MOTOR BRUSH CAPS
