the deflation process starts, during which time the main unit
detects pressure oscillations generated by beat-to-beat
pulsatile, which is used to determine the systolic, mean and
diastolic pressure, and also your pulse rate. Any motion during this
period will result in an incorrect measurement. After all readings
are determined and displayed on LCD, the measurement is finished
and the wrist cuff automatically deflates.
E
NOTE
· Replace the batteries whenever the weak battery mark
(
) shows, the display is dim, or the display does not
illuminate when the power is on. Replace all the batteries
at the same time – it is dangerous to mix old and
new batteries.
· Contact your local waste disposal authority for instructions
on how to dispose of used batteries. Used Batteries can
be harmful to the environment, and should not be thrown
out with household trash.
SETTING THE DATE, TIME, AND MEASUREMENT UNIT
It is important to set the clock before using your blood pressure
monitor, so that a time stamp can be assigned to each record
that is stored in the memory.
1. Press and hold SET for 2 seconds to enter the setting
mode.
The setting order is as follows: 12/24 hour format, hour,
minute, year, month/day or day/month format, month,
date, and measurement unit (mmHg or kPa).
2. Press MEM / UP to increase a value or change the setting.
3. Press SET to accept the change and switch to the next
setting.
4. When you are finished, press
to exit the setup menu.
Figure 5cFigure 5bFigure 5a
GETTING STARTED
INSTALLING AND REPLACING THE BATTERIES
To install the batteries:
1. Slide off the battery cover (Figure 5a).
2. Install the batteries by matching the correct polarity,
as shown by Figure 5b. Always use the correct
battery type (2 Alkaline LR03 AAA-size).
3. Replace the cover (Figure 5c).
P/N: 086L003591-148 REV1
Page 7 of 122
