48
Chapter 6: Maintaining Your Filtered Enclosure
Apparatus
1. An aerosol photometer ATI model 2D, 2E, 2G or
equivalent. Air Techniques Hamilton Associates inc. 11403
Cron Ridge Dr. Owings Mills, MD 21117
2. One aerosol generator of the Laskin nozzle(s) type. An
aerosol of mineral oil or suitable liquid shall be created by
flowing air through it. The compressed air supplied to the
generator should be adjusted to a pressure of 10± 1 psig. during
operation. Air Techniques Inc. Model TDA-4A or equal. One
nozzle at 10 psig is (67.5 cfm x 100ug/l)/(Vol. of air), For the
2' at 90 fpm or 130 cfm, one nozzle @10 psig is 13,500/130
cfm = 52 ug/l. For the 3' at 90 fpm or 200 cfm, one nozzle @
10 psig is 34 ug/l. For the 4' at 90 fpm or 265 cfm, one nozzle
at 10 psig is 26 ug/l.
3. Mineral oil (Catalog #1491400).
4. Sampling Nozzle, Rectangular 1/2" x 3-1/4", Air Techniques,
Inc.
Procedure
For the ATI 2G Photometer
1. Turn on the photometer and allow it to operate for a minimum
of 5 minutes. Leave the valve in the “CLEAR” setting.
2. Press the “ENTER” keypad. Press the “REF” keypad.
3. The display will display “P1” for approximately 1 second, and
then display a numerical value.
4. Using the “^” or “ν” keypads, respectively, increase or
decrease the numerical value until it equals 52 (2'), 34 (3'). 26
(4') for the enclosure at 90 fpm inflow velocity.
5. Press the “ENTER” Keypad. The photometer will scan for 15
seconds, and then the “0” keypad will flash. Press the “Enter”
keypad. The unit will scan for 5 seconds, the display will read
“0000,” and the unit will sound a confirming tone.
6. Set the valve to “DOWNSTREAM.” Place the palm of your
hand over the sampling port of the pistol. There should be a
strong vacuum at this port. If the vacuum is weak, contact Air
Techniques Hamilton Associates.
7. Turn the enclosure on and let it operate for a minimum of 5
minutes.
