10
Chapter 2: Prerequisites
Proper blower selection can be determined from these exhaust
requirements and the total system static pressure loss. For outside
exhaust, the enclosure must be connected to either a dedicated
blower or a house exhaust system.
Labconco offers accessory remote blowers listed in Chapter 7.
Contact Labconco for blower sizing assistance.
If the enclosure is connected directly to a house exhaust system, an
adjustable damper (or valve) must be installed to control the
airflow properly. This is equally important when a house exhaust
system is controlling multiple filtered enclosures. See Chapter 7
for accessory adjustable damper ordering information.
Electrical Requirements
Standard duplex electrical receptacles should be nearby for
connecting the filtered enclosure, or other equipment, such as a
balance for weighing operations. The enclosures include iris pass-
throughs to allow electrical cords through the back of the enclosure
without leaving a large hole for contaminants to escape.
The remote blower for the XPert Filtered Balance Station may be
connected to the blower switch on the enclosure. The blower
switch is connected to a relay whose wires are terminated in the
junction box behind the front panel. We recommend a maximum
amperage of 6 amps for this circuit to the remote blower. Please
refer to the wiring diagrams in Appendix C. Connect the blower
wires inside the junction box to the remote blower per local
electrical codes.
Space Requirements
The dimensions for the different models are shown in Appendix B:
Dimensions.
!
XPert
Station
