LCD Display
All basic functions
(UP, DOWN and
STOW) should
show a value of 1
when activated via
a controlled input
(Hand-held Pendant,
Magnetic, Remote
Entry or 3rd Station
Controls).
Moving Out
Of Cassette
Full Out Moving
Up
At Floor
Level
Moving
Down
Ground
Level
Ground Level
OB Out
BEL ST SW 1 1
LOUT SW 1
FOUT SW 1 1 1 1 1 1
FLV SW 1
OBAR SW 1 1 1 1 1 1 1
GND LVL 1 1
HRBELT SW = 1 When Seat Belt is Plugged In.
MAT SW = 1 When Mat is Activated
IBAR SW = 1 When IN Barrier is activated
DO SW = 1 When Door is Full Open. Or pin 3 and pin 4 are jumpered.
LO VOLT
STOW
DOWN UP
V104
102
102
102
D7
D8
D5
D6
D3
D4
D
2
R31
cycle
C6
C
T
S
L
V
1
W
S
LCD Diagnostic Codes
When all of the harnesses are correctly
connected to the control board, the values
shown in the chart below will display when
the corresponding action is taken. “1” will
appear on the LCD module as shown in the
Illustration at right. If any other value ap-
pears on the LCD screen during the specific
diagnostic procedure, verify that the correct
harness is properly connected to both the
control board and the associated lift harness.
Repeat the harness diagnostic procedure. If
an incorrect value is still present after check-
ing the harness and connections, contact
The Braun Corporation Product Support
Department at 1-800-THE-LIFT
®
.
Hand-held Pendant
Stowed
