13
Tip: You can also select a channel of a multi-tier KVM system using the OSD menu. See the
section “7.2.2 Select a Second- or Third-Tier Channel.”
6.5. Disable or Enable the Buzzer
To disable or enable the buzzer function, press <Scroll Lock> twice, then <B> and
<Enter>. The buzzer is enabled by default.
<Scroll Lock> + <Scroll Lock> + <B> + <Enter>
Tip: You can also enable/disable the buzzer by pressing <F1> in the OSD main menu. See the
section “7.3.6 Sound.”
.
Figure 13: Hot key for buzzer
6.6. Auto-Scan Function
After enabling the Auto-Scan function, the KVM switch will cycle through all channels
and display them one by one on the screen. At this time, both of the mouse and
keyboard are disabled to prevent any accidental operation errors, such as erratic
movement of the mouse or wrong inputs.
6.6.1. Enable the Auto-Scan Function
To activate the Auto-Scan function, press <Scroll Lock> twice, then <S> and
<Enter>.
<Scroll Lock> + <Scroll Lock> + <S> + <Enter>
A banner will be shown on the screen to indicate the currently-scanned channel.
