318 Océ TDS600 Multifunctional Digital System User Manual
Safety data sheet Océ TDS600 scanner
Note:
The contents of this safety data sheet is subject to the disclaimer on
page 316 of this manua
PRODUCT SAFETY DATA SHEET
Océ-(UK), Ltd
Number E-692-a-UK
Date December 1999
Copyright © 1999 Océ-Technologies B.V., Venlo, NL
Model Océ 9600 Scanner
Description Free standing wide format scanner
Max. process speed 5 m/min
Dimensions Width 1314 mm
Depth 583 mm
Height 1353 mm
Weight 90 kg
Voltage 230 V
Frequency 50-60 Hz
Current-rated 1A
Current-max 1A
Power consumption, operation 110 W at continuous operation
Power consumption, stand by 97 W
Mains connection Cable with plug
Safety class I (IEC 536) Protective earth connection
Protection class IP20 (IEC 529)
Sound pressure level
(at operator position)
Stand by In operation
26 dB(A) main body 52 dB(A)
impulse ∆ L
i
= 4 dB(A)
Sound power level 43 dB(A) main body 62 dB(A)
Radio interference Complies with Directive 89/336/EEC
Radiation Below the Threshold Limit Values for UV,Visible and IR radiation (TLV list of ACGIH)
Heat emission Standby 97 W; at continuous operation 110 W
Ozone emission Not applicable
Room volume No special requirements
Room ventilation
Consumables Notapplicable
Additional safety information None
CE-Compliance Approved according to Approved according to
Low Voltage Directive EMCDirective
73/23/EEC 89/336/EEC
