294 Océ TDS600 Multifunctional Digital System User Manual
Maximum folding settings for long plots
First fold output Stacker 2nd fold Stacker 2nd fold Belt 2nd fold
Paperdensity
[g/m
2
]
1st fold
[mm / inch]
2folds
[mm / inch]
3 folds
[mm / inch]
2folds
[mm / inch]
60 1220 / 48 1220 / 48 1220 / 48 1220 / 48
75 6000 / 236 2500 / 98 2000 / 79 1220 / 48
110 2500 / 98 1220 / 48 not possible 1220 / 48
[195] Folding settings for long plots
Folding settings 75 grams
Output length Delivery
‘Stacker’ or ‘Belt’
selected
< 2.5 m Delivered on stacker or belt
2.5 m - 6 m First fold only, delivered in
first fold delivery
>6m
length known at start
Unfolded, delivered in first fold
delivery
>6m
length not known at start
Possible paper jam
‘First fold only’ selected < 6 m Delivered in first fold delivery
>6m
length known at start
Unfolded, delivered in IRT
>6m
length not known at start
Possible paper jam
[196] Folding settings 75 grams
Folding settings 110 grams
Output length Delivery
‘Stacker’ or ‘Belt’
selected
<1.22m
(3 folds)
Delivered in first fold delivery
<1.22m
(2 folds)
Delivered on stacker or belt
>1.22m
<2.5m
Delivered in first fold delivery
> 2.5 m Unfolded, delivered in IRT
‘First fold only’ selected < 2.5 m Delivered in first fold delivery
> 2.5 m Unfolded, delivered in IRT
[197] Folding settings 110 grams
