NDA-24296 CHAPTER 3
Page 613
Revision 1.0
PA-24DTR (DLI)
Digital Line Interface
Note:
This PAD value table is PAD pattern 1. If other PAD pattern is required, assign PAD pattern by elements
4~6 of SW12/58. The elements become valid when assigning ASYD SYS1 INDEX4 bit5=1. When ASYD
SYS1 INDEX4 bit5=0, PAD value is 0dB.
SWITCH
NAME
SWITCH
NO.
SETTING
STANDARD
SETTING
MEANING
SW13/6C
1
ON Main Signal All 1 Supervision: Valid
OFF
×
Main Signal All 1 Supervision: Invalid
2
ON
×
Ringer Control: Continuous
OFF Ringer Control: Intermittent
3
ON
Sending PAD Value Selection (PAD Pattern1) Note
OFF
×
4
ON
OFF
×
5
ON
×
OFF
6
ON
Receiving PAD Value Selection (PAD Pattern1) Note
OFF
×
7
ON
OFF
×
8
ON
OFF
×
SW13/6C-3 SW13/6C-4 SW13/6C-5 PAD Value
OFF OFF OFF 0 dB
OFF OFF ON 2 dB
OFF ON OFF 4 dB
OFF ON ON 6 dB
ON OFF OFF 8 dB
ON OFF ON 0 dB
ON ON OFF 0 dB
ON ON ON 0 dB
SW13/6C-6 SW13/6C-7 SW13/6C-8 PAD Value
OFF OFF OFF 0 dB
OFF OFF ON 2 dB
OFF ON OFF 4 dB
OFF ON ON 6 dB
ON OFF OFF 8 dB
ON OFF ON 0 dB
ON ON OFF 0 dB
ON ON ON 0 dB
