CHAPTER 2 NDA-24296
Page 164
Revision 1.0
PZ-PC22
Local Area Network Interface
2. Mounting Location/Condition
The PZ-PC22 (LANI) card is accommodated on the PCI bus in the CPR as shown in Figure 2-88.
Figure 2-88 Location of PZ-PC22
3. Face Layout of Connectors
The face layout of lamps, switches, and connectors are shown in Figure 2-89.
Figure 2-89 Face Layout of PZ-PC22 (LANI) Card
5.0
A
CMP-CPR/LP-CPR
PCI bus ISA bus
PZ-PW92
DC-40V -58.6
I
O
SW
ON
OFF
ON
ALM
PALM
OUTPWR
INPWR
5A
125V
AC/DC
CPUOPE WDT IMG0
PZ-PC22
100M
TXRX
LINK
COL
LAN
