3 Interface Devices and Mass-Storage Drives
Connectors and Sockets
PCI Connector
Pin Signal Pin Signal Pin Signal Pin Signal
B1 -12 V A1 TRST# B47 AD[12] A47 AD[11]
B2 TCK A2 +12 V B48 AD[10] A48 Ground
B3 Ground A3 TMS B49 + 3.3 V A49 AD[09]
B4 TDO A4 TDI B50 AD[08] A50 C/BE#[0]
B5 +5 V A5 +5 V B51 AD[07] A51 + 3.3 V
B6 +5 V A6 INTA# B52 Ground A52 AD[06]
B7 INTB# A7 INTC# B53 AD[05] A53 AD[04]
B8 INTD# A8 +5 V B54 AD[03] A54 Ground
B9 Ground A9 reserved B55 Ground A55 AD[02]
B10 reserved A10 PRSNT# B56 AD[01] A56 AD[00]
B11 + 3.3 V A11 reserved B57 +5 V A57 +5 V
orientation key orientation key B58 +5 V A58 +5 V
B12 reserved A12 reserved B59 +5 V A59 +5 V
B13 Ground A13 RESET# B60 ACK64# A60 REQ64#
B14 CLK A14 + 3.3 V orientation key orientation key
B15 Ground A15 GNT# B61 reserved A61 Ground
B16 REQ# A16 Ground B62 Ground A62 C/BE#[7]
B17 + 3.3 V A17 reserved B63 C/BE#[5] A63 C/BE#[6]
B18 AD[31] A18 AD[30] B64 C/BE#[4] A64 + 3.3 V
B19 AD[29] A19 Ground B65 Ground A65 PAR64
B20 Ground A20 AD[28] B66 AD[63] A66 AD[62]
B21 AD[27] A21 AD[26] B67 AD[61] A67 Ground
B22 AD[25] A22 + 3.3 V B68 + 3.3 V A68 AD[60]
B23 Ground A23 AD[24] B69 AD[59] A69 AD[58]
B24 C/BE#[3] A24 IDSEL B70 AD[57] A70 Ground
B25 AD[23] A25 Ground B71 Ground A71 AD[56]
B26 + 3.3 V A26 AD[22] B72 AD[55] A72 AD[54]
B27 AD[21] A27 AD[20] B73 AD[53] A73 + 3.3 V
B28 AD[19] A28 Ground B74 Ground A74 AD[52]
B29 Ground A29 AD[18] B75 AD[51] A75 AD[50]
B30 AD[17] A30 AD[16] B76 AD[49] A76 Ground
B31 C/BE#[2] A31 + 3.3 V B77 + 3.3 V A77 AD[48]
B32 Ground A32 FRAME# B78 AD[47] A78 AD[46]
B33 IRDY# A33 Ground B79 AD[45] A79 Ground
B34 + 3.3 V A34 TRDY# B80 Ground A80 AD[44]
B35 DEVSEL# A35 Ground B81 AD[43] A81 AD[42]
B36 Ground A36 STOP# B82 AD[41] A82 + 3.3 V
B37 LOCK# A37 + 3.3 V B83 Ground A83 AD[40]
B38 PERR# A38 SDONE B84 AD[39] A84 AD[38]
B39 Ground A39 SBO# B85 AD[37] A85 Ground
B40 SERR# A40 Ground B86 + 3.3 V A86 AD[36]
B41 + 3.3 V A41 C/BE#[1] B87 AD[35] A87 AD[34]
B42 AD[15] A42 PAR B88 AD[33] A88 Ground
B43 + 3.3 V A43 + 3.3 V B89 Ground A89 AD[32]
B44 + 3.3 V A44 + 3.3 V B90 reserved A90 reserved
B45 AD[14] A45 + 3.3 V B91 reserved A91 Ground
B46 Ground A46 AD[13] B92 Ground A92 reserved
