3 Interface Devices and Mass-Storage Drives
S3 Trio 64V2 Graphics Controller Chip
The extended modes supported by the video BIOS are:
Extended Video Modes with 1 MB DRAM
Extended
Mode No.
VESA
Mode No.
Interface
Type
Resolution
No. of
Colors
Vertical
Refresh
(Hz)
Horizontal
Refresh
(kHz)
Dot Clock
(MHz)
4Eh 207h graphics 1152 x 864 256 60 55 80.000
4Fh 208h graphics 1280 x 1024 8 60 63.7 110.000
51h 212h graphics 640 x 480 16.7 M 60 31.5 25.000
52h 213h graphics 640 x 400 16.7 M 70 31.5 25.000
54h 10Ah text 132 x 43 chars 16 70 31.5 40.000
55h 109h text 132 x 25 chars 16 70 31.5 40.000
65h 10Dh graphics 320 x 200 32,768 70 12.540
66h 10Eh graphics 320 x 200 65,536 70 12.540
67h 10Fh graphics 320 x 200 16.7 M 70 12.540
68h 100h graphics 640 x 400 256 70 31.5 25.175
69h 101h graphics 640 x 480 256 60 31.5 25.175
69h 101h graphics 640 x 480 256 72 37.9 31.500
69h 101h graphics 640 x 480 256 75 37.5 31.500
69h 101h graphics 640 x 480 256 85 45 36.000
6Ah 102h graphics 800 x 600 16 60 37.9 40.000
6Ah 102h graphics 800 x 600 16 72 48.1 50.000
6Ah 102h graphics 800 x 600 16 75 47.5 49.500
6Ah 102h graphics 800 x 600 16 85 53.6 56.000
6Bh 103h graphics 800 x 600 256 60 37.9 40.000
6Bh 103h graphics 800 x 600 256 72 48.1 50.000
6Bh 103h graphics 800 x 600 256 75 46.8 49.500
6Bh 103h graphics 800 x 600 256 85 53.6 56.000
6Ch 104h graphics 1024 x 768 16 60 48.4 65.000
6Ch 104h graphics 1024 x 768 16 70 56.5 75.000
6Ch 104h graphics 1024 x 768 16 75 60.2 80.000
6Ch 104h graphics 1024 x 768 16 85 68.7 95.000
6Dh 105h graphics 1024 x 768 256 60 48.4 65.000
6Dh 105h graphics 1024 x 768 256 70 56.5 75.000
6Dh 105h graphics 1024 x 768 256 75 60.0 80.000
6Dh 105h graphics 1024 x 768 256 85 68.7 95.000
6Eh 106h graphics 1280 x 1024 16 60 110.000
70h 110h graphics 640 x 480 32,768 60 31.5 25.175
70h 110h graphics 640 x 480 32,768 72 37.5 31.500
70h 110h graphics 640 x 480 32,768 75 37.5 31.500
70h 110h graphics 640 x 480 32,768 85 45 36.000
