3 Interface Devices and Mass-Storage Drives
S3 Trio 64V2 Graphics Controller Chip
Video Modes
Standard and Enhanced Video Graphics Array (VGA) modes are available.
Hardware acceleration of graphical user interface (GUI) operations is
provided, and acceleration for 8, 16 and 32-bit pixel depths.
The following table details the standard VGA modes which are currently
implemented in the video BIOS. These modes are supported by standard
BIOS functions. The video BIOS (which is mapped contiguously in the
address range C0000h to C7FFFh) contains all the routines required to
configure and access the graphics subsystem.
Standard VGA Modes
Mode No. Standard
Interface
Type
Resolution
No. of
Colors
Vertical
Refresh
(Hz)
Horizontal
Refresh
(kHz)
Dot Clock
(MHz)
00h VGA text 40 x 25 chars b/w 70 31.5 25.175
00h* VGA text 40 x 25 chars b/w 70 31.5 25.175
00h+ VGA text 40 x 25 chars b/w 70 31.5 28.322
01h VGA text 40 x 25 chars 16 70 31.5 25.175
01h* VGA text 40 x 25 chars 16 70 31.5 25.175
01h+ VGA text 40 x 25 chars 16 70 31.5 28.322
02h VGA text 80 x 25 chars b/w 70 31.5 25.175
02h* VGA text 80 x 25 chars b/w 70 31.5 25.175
02h+ VGA text 80 x 25 chars b/w 70 31.5 28.322
03h VGA text 80 x 25 chars 16 70 31.5 25.175
03h* VGA text 80 x 25 chars 16 70 31.5 25.175
03h+ VGA text 80 x 25 chars 16 70 31.5 28.322
04h VGA graphics 320 x 200 4 70 31.5 25.175
05h VGA graphics 320 x 200 4 70 31.5 25.175
06h VGA graphics 640 x 200 2 70 31.5 25.175
07h VGA text 80 x 25 chars b/w 70 31.5 28.322
07h+ VGA text 80 x 25 chars b/w 70 31.5 28.322
0Dh VGA graphics 320 x 200 16 70 31.5 25.175
0Eh VGA graphics 640 x 200 16 70 31.5 25.175
0Fh VGA graphics 640 x 350 b/w 70 31.5 25.175
10h VGA graphics 640 x 350 16 70 31.5 25.175
11h VGA graphics 640 x 480 2 60 31.5 25.175
12h VGA graphics 640 x 480 16 60 31.5 25.175
13h VGA graphics 320 x 200 256 70 31.5 25.175
