1 Administration Overview UCS 1000 R4.2 User Interface
UCS 1000 R4.2 Administration 585-313-507 Issue 3 April 2000 14
Table 3. Optional Function Key Labels
Function Key
Label
Description
F2 (Choices) Opens a menu screen containing choices for the
current field, if there is a finite set of choices for a
particular field. Move the cursor to the field you want
to fill and press
F2 (CHOICES). The CHOICES
menu opens, displaying the options available for that
field.
F2 (Prevpage) Scrolls back one full page, towards the beginning of
text that is too long to fit within the active screen or
window.
F3 (Nextpage) Scrolls forward, toward the end of text that is too
long to fit within the active screen, menu, or window.
For example, pressing
F3 in Figure 11 on page 12
orders the system to move to the next page, while
pressing
F3 in Figure 12 on page 16 sounds a beep,
but does nothing else because that key is “empty.”
F3 (Save) Preserves all changes made to the screen.
F4 (Top) Scrolls toward the top of a page.
1 of 2
