28 Common messages
EN
CLEAR FUSER JAM
LOWER LEFT DOOR
See “Removing jammed media” on page 15.
CLEAR INPUT JAM
See “Removing jammed media” on page 15.
CLEAR OUTPUT JAM
UPPER LEFT DOOR
See “Removing jammed media” on page 15.
CLEAR PAPER JAM
See “Removing jammed media” on page 15.
CLEAR TRANSFER
JAM
See “Removing jammed media” on page 15.
CLEAR TRAY 4 JAM
See “Removing jammed media” on page 15.
CLEAR UNEXPECTED
PAPER SIZE JAM
THEN LOAD TRAY 1
<TYPE> <SIZE>
See “Removing jammed media” on page 15.
CLEARING PAPER
FROM PRINTER
No action is required.
CLOSE
<LOCATION> DOOR
Close the door indicated in the message.
DRUM ERROR
REPLACE DRUM KIT
Printing cannot continue until the drum kit has
been replaced.
DRUM LIFE LOW
REPLACE DRUM KIT
Although printing can continue, the drum kit
should be replaced for optimum printer unit
operation.
DRUM LIFE OUT
REPLACE DRUM KIT
Printing cannot continue until the drum kit has
been replaced.
DUPLEX ERROR
CHECK DUPLEXER
Remove the duplexer. Check for and remove
any jammed media from the duplexer and
reinstall the duplexer.
FACE UP
OUTPUT BIN FULL
Remove all media from the left output tray.
Printer unit control panel messages (continued)
Control panel message Recommended action
